| 开发编号 |
MS-6702 |
| 对应CPU |
AMD Athlon64 Processor 3200+ 以上 |
| Socket |
Socket 754 |
| System Bus |
200/400/600/800MHz |
| Chip Set |
VlA K8T800 + VT8237 |
| Memery |
三插槽 (最大支持2GB)
Single Channel DDR266/333/400 (Unbuffered) |
| Lan Card Chip |
Realtek RTC8110S 1000BASE-T |
| IDE/S-ATA |
ATA133*2 (最多4台)
S-ATA150*2 (最多8237/2台)
S-ATA150*2 (最多Promise/2台) |
| IDE RAID/S-ATA RAID |
VIA VT8237 (0,1)
PromiseR PDC20378(0,1,0+1) |
| 扩展接口 |
AGP 8X *1 PCI *5 |
| USB 2.0 |
6接口(内部2接口为D-Bracket2型) |
| IEEE 1394 |
6pin *1 S400(4pin) *1 |
| 音频输出 |
RealtekR ALC655 6ch AC97
SPDIF输出 (同轴电缆/光端子/IO Port) |
| Form factor |
ATX(305*245mm)/ATX |
| 所需电源 |
ATX |
|
